Chapter 10, Signaling Encoder (AF Generator 2)
EDACS Encoder
Signaling Dev
This field is used to specify the high-speed data level. The unit-of-measure used
depends on the
AFGen2 To setting.
• When AFGen2 To is set to FM, the displayed units are kHz or Hz. This is the normal-
ly-used setting for testing EDACS radios.
• When AFGen2 To is set to AM, the displayed unit is %.
• When AFGen2 To is set to Audio Out, the displayed units are µV, mV, or V.
See Also
AFGen2 To
field description, on page 383
Site ID
This field is used to specify the identification number of the repeater site being
simulated by the encoder.
Standard
This field specifies the signaling standard used by the radio: 4800 bps
(narrowband) or 9600 bps (wideband). In addition to telling the encoder and
decoder which system is being used, this field presets the values of certain fields
as shown in the following table.
Field
Standard
9600 4800
Data Rate 9600.0 4800.0
Signaling Dev 3.00 1.80
Sub-Audible Dev 750 350
(Encoder) Polarity Norm Invert
