Chapter 3, Operating Overview
Interaction Between Screens
Using your Test Set, duplicate the steps in figure 7 to demonstrate how the
Priority fields operate.
Table 3 Priority RX TEST and TX TEST Fields
Priority Field RX TEST TX TEST
RF Gen Amplitude Presets to −80 dBm (changeable) Always Off
AFGen1 To Presets to FM (changeable) Always Audio Out
AF Anl In Always Audio In Presets to FM Demod (changeable)
Detector Always RMS Presets to Pk +− Max (changeable)
De-emphasis Always Off
Presets to 750 (changeable)
AF Anl Measurement Presets to SINAD (changeable) Presets to Audio Freq (changeable)
µs
