Chapter 25, Modifications, Accessories, Manuals, Support
Modifications
a. This option reduces the maximum input power of the HP 8920A from 60 watts to 2.4 watts. It cannot be
ordered with Option 008 or H08.
b. Firmware upgrade kit included with option retrofit kit.
c. This option reduces the maximum input power of the HP 8920A from 60 watts to 6 watts. It cannot be
ordered with Option 008 or H08.
d. A maximum of two filters options can be added to an instrument.
e. Included high stability timebase and improved residual FM performance.
f. Retrofit kit can only be installed in instruments with serial prefix 3248A and above.
g.Retrofit kit does not include firmware. 1, 2, 10 dB resolution requires firmware revi sion A.06.01 or
later. ACP (Adjacent Channel Power) measurement capability requires revision A.12.01, or later.
Option 014
d
: 6 kHz Bandpass Filter
R14
Option 019: Variable Frequency Notch Filter, 300 Hz - 10 kHz R19
Option 020: Radio Interface Card
R20
b
Option 050: Dual-mode Rear Panel Connectors R50
ef
Firmware Upgrade Kit R98
Option 102: Spectrum Analyzer with Tracking Generator R02
g
Option 103: HP-IB/RS-232/Parallel Port/DC Current Measurement R93
Table 15 Hardware Retrofits and Modifications
Description HP 8920A
