Chapter 25, Modifications, Accessories, Manuals, Support

Accessories

Plug Type

Plug Descriptions

male/female

HP Part #

(cable &plug)

Cable Descriptions

Straight/Straight

Straight/90°

8120-4753

8120-4754

90 inches, dark

gray 90 inches,

dark gray

Used in the following locations

Japan

Plug Type

Plug

Descriptions

male/female

HP Part #

(cable &plug)

Cable Descriptions

90°/Straight

90°/90°

Straight/Straight

8120-2956

8120-2957

8120-3997

79 inches, gray 79 inches, gray 79

inches, gray

Used in the following locations

Denmark

Greenland

JIS C 8303, 100 V
