Chapter 5: Console Operation
Output Channels: UM8 Processed Outputs
Eclipse User Guide 2.0 177/ 526
UM8 Processed Outputs
Each bus which is patched to a UM-8PO output can access a
full range of DSP processing provided by the card itself.
You should use output processing when you want to treat a
specific destination. For example, to patch a single Matrix bus
to multiple outputs each with its own delay time, EQ, etc.
Every UM8-PO output provides:
• Output gain (adjustable from +10.5dB to +22 dB)
• Phase reverse
• Delay – up to 1365ms
• Compressor/Limiter
• Gate/Expander
• 8-band Parametric EQ
• 31-band Graphic EQ
