Chapter 6: Console Configuration
The Patch Input Display
Eclipse User Guide 2.0 239/ 526
Patching Tips
The following tips make patching on Eclipse quick and easy:
• Use the ST AUTO option to quickly configure mono and
stereo channels as you patch.
• To make consecutive mono patch points, press [SHIFT]
on the console keyboard and click and drag diagonally
across the grid.
• You can assign rotary controls on the User Defined
panel to select the x-axis and y-axis within the patch
grid. Switches may be assigned to action crosspoints or
edit labels. See Page 322 for details.
• If you have a mono channel which is already patched
and labelled (e.g. OH L), and you turn it into a stereo
channel, then the Label updates to SIN for stereo input.
Use [F3] to edit the stereo FADER Label.
