Chapter 6: Console Configuration
Ethersound Networks
266/ 526 2.0 Eclipse User Guide
Advanced Ethersound Networks
To add more DioCores or other Ethersound devices, insert
each device into the middle of the chain. This keeps Eclipse as
the Primary Master and M.A.R.S. as the last device in the
chain.
Note that if a device fails, then the previous device in the chain
automatically loops the downstream data back onto the
upstream path without any break in audio.
When more than one console exists, then you may wish to use
either of the following configurations:
Example 1:
The FOH Eclipse is the Primary Master and defines the
Ethersound network and streaming direction. The monitoring
console cannot detect DioCores or change the data flow, but it
can patch Ethersound channels to or from its faders.
In this configuration, the replay tracks from the FOH M.A.R.S.
will affect feeds to both the FOH and monitoring consoles when
running in VSC or Broadway mode.
