Page #283 background image
Layout Review Checklist
R
Intel
®
Pentium
®
4 Processor / Intel
®
850 Chipset Family Platform Design Guide 283
16.4.2 2X/4X Signals
The 2X/4X signals are: AD[31:0], C/BE[3:0]#, ADSTB[1:0]#, SBA[7:0], SB_STB, SB_STB#
16.4.2.1 AGP Less Than 6 Inches
Recommendations Reason/Impact
5 mil trace width 15 mil separation between
data to data for 60
±10%; for 60 ±15%,
its 20 mils
Refer to Section 7.1.2.1.
5 mil trace width 20 mil separation between
data (and all other signals) to strobes for
60
±10% and 60 ±15%
Refer to Section 7.1.2.1.
5 mil trace width 15 mil separation between
strobe-to-strobe for 60
±10%; for
60
±%, its 20 mils
Refer to Section 7.1.2.1.
If AGP Interface is <6 inches long, then
DATA and C/BE#s need to be length
matched within ±.25 inches of strobes.
Refer to Section 7.1.2.1.
Strobe pairs must be length matched
±0.1 inches
Refer to Section 7.1.2.1.
Route AD [15:0], C/BE [1:0]#, AD_STB0,
and AD_STB0# together. (Good
recommendation, but not in AGP
specification)
Signals to be kept on same layers.
Microstrip-to-microstrip and stripline-to-
stripline.
Refer to Section 7.1.2.1.
Route AD [31:16], C/BE [3:2]#, AD_STB1,
and AD_STB1# together. (Good
recommendation, but not in AGP
specification)
Signals to be kept on same layers.
Microstrip-to-microstrip and stripline-to-
stripline.
Refer to Section 7.1.2.1.
Route SBA [7:0], SB_STB, SB_STB#
together. (Good recommendation, but not in
AGP specification)
Signals to be kept on same layers.
Microstrip-to-microstrip and stripline-to-
stripline.
Refer to Section 7.1.2.1.
Recommended that all strobes be ground
referenced as well as TRDY#, IRDY#,
GNT#.
Refer to Section 7.1.5.
Recommended that ½ the AGP signals are
ground referenced.
Refer to Section 7.1.5.
For signals that require pull-up or pull-down
resistors, keep stub less than 0.5 inches for
1X signals and 0.01 inches for 2X/4X
signals.
This is to minimize signal reflections from
the stub.
Refer to Section 7.1.9.
Pour a Ground flood under the V
DDQ
plane Optimizes the mutual inductance between
two planes.
Refer to Section 7.1.4.
