DACS-W Operation Manual 8 ADDITIONAL FUNCTIONS
8-5
Table 8-2 Installation Engineer Level Functions (2)
Key Display Function
Reject Setting Output Signal 1 ON Time Defines length of time Output Signal 1 is output. (Setting range: 0-
29999ms)
When value is set to 30000ms, the signal will be output
continuously. [See "8.4.2.17 Output Signal 1 ON Time"]
Output Signal 2 ON Time Defines length of time Output Signal 2 is output. (Setting range: 0-
29999ms)
When value is set to 30000ms, the signal will be output
continuously. [See "8.4.2.18 Output Signal 2 ON Time"]
Output Signal 3 ON Time Defines length of time Output Signal 3 is output. (Setting range: 0-
29999ms)
When value is set to 30000ms, the signal will be output
continuously. [See "8.4.2.19 Output Signal 3 ON Time"]
Output Signal 4 ON Time Defines length of time Output Signal 4 is output. (Setting range: 0-
29999ms)
When value is set to 30000ms, the signal will be output
continuously. [See "8.4.2.20 Output Signal 4 ON Time"]
Reject Buzzer ON Time Defines length of time reject buzzer sounds. (Setting range: 0-
29999ms)
When value is set to 30000ms, the buzzer will sound continuously.
[See "8.4.2.21 Reject Buzzer ON Time"]
Continuous N/G Stop Sets whether checkweigher will be stoped when consecutive N/G
packs occur. [See "8.4.2.22 Continuous N/G Stop"]
Cout. N/G Output Sig. Sets the signal to be output when auto stop occurs due to Continuous
N/G Stop status.
[See "8.4.2.23 Continuous N/G Output Signal"]
System
Configuration
Weight Display The following weight values can be displayed during operation:
*Absolute Value: The actual weight value is displayed.
*Deviation Value: The degree of deviation from the reference value
is displayed.
[See "8.4.3.1 Weight Display"]
Metal Detection Sets whether an individual, integrated or no metal detector is
connected.) [See "8.4.3.2 Metal Detection"]
Printer Defines whether an optional printer is mounted. [See "8.4.3.3
Printer"]
Reject Device Defines the type of rejector device which is installed. [See "8.4.3.4
Reject Device"]
Tare Subtraction Set to ON when Tare Subtraction is activated. [See "8.4.3.5 Tare
Subtraction"]
