Figure 36: Installing the PTX5000 Packet Transport Switch in an
Open-Frame Rack
g006186
Center-mounting
bracket
Open frame rack
79Copyright © 2012, Juniper Networks, Inc.
Chapter 8: Installing the PTX5000 Packet Transport Switch Using a Mechanical Lift
