PTX5000 Field-Replaceable Units
Field-replaceable units (FRUs) are packet transport switch components that can be
replaced at the customer site. Replacing most FRUs requires minimal packet transport
switch downtime. The packet transport switch uses the following types of FRUs:
•
Hot-removable and hot-insertable FRUs—You can remove and replace these
components without powering off the packet transport switch or disrupting the routing
functions.
•
Hot-pluggable FRUs—You can remove and replace these components without powering
down the packet transport switch, but the routing functions of the system are
interrupted when the component is removed.
Before you replace a component in the host subsystem, you must take the host subsystem
offline.
Table 41 on page 156 lists the FRUs for the packet transport switch.
Table 41: Field-Replaceable Units
Hot-Pluggable FRUsHot-Removable and Hot-Insertable FRUs
SIBs (if fewer than eight SIBs are operational)
Master control board (if nonstop active routing
is not configured)
Nonredundant control board
Master Routing Engine (if nonstop active routing
is not configured)
Nonredundant Routing Engine
Air filters
Craft interface
Horizontal and vertical fan trays
Power supplies
SIB (if at least eight other SIBs are operational)
Backup control boards
Master control boards (if nonstop active routing
is configured)
Backup Routing Engines
Master Routing Engines (if nonstop active
routing is configured)
Related
Documentation
PTX5000 Hardware Component Overview on page 9•
• PTX5000 Component Redundancy on page 11
Tools and Parts Required for Replacing Hardware Components
To replace hardware components, you need the tools and parts listed in Table 42 on
page 157.
Copyright © 2012, Juniper Networks, Inc.156
PTX5000 Packet Transport Switch Hardware Guide
