Juniper PTX Series - Replacing a PTX5000 PDU; Removing a PTX5000 PDU; Figure 70: Installing a Vertical Fan Tray

Figure 70: Installing a Vertical Fan Tray
g006170
FANTRAY
PTX
VERTICAL
Related
Documentation
PTX5000 Cooling System Description on page 18•
• PTX5000 Craft Interface LEDs on page 28
• Troubleshooting the PTX5000 Cooling System on page 122
• Preventing Electrostatic Discharge Damage to a PTX5000 Packet Transport Switch
on page 222
Replacing a PTX5000 PDU
1.
Removing a PTX5000 PDU on page 194
2.
Installing a PTX5000 PDU on page 197
Removing a PTX5000 PDU
The PTX5000 Packet Transport Switch has two redundant, load-sharing PDUs. Each
PDU is hot-insertable and hot-removable. The PDU weighs 60 lb (27.3 kg). Each input
power tray weighs 1.6 lb (0.7 kg).
