Figure 63: Connecting Fiber-Optic Cable to a PIC
g006197
1
0
1
0
1
0
Related
Documentation
PTX Series PIC Description on page 36•
• Troubleshooting the PTX5000 PICs and PIC Cables on page 147
• Preventing Electrostatic Discharge Damage to a PTX5000 Packet Transport Switch
on page 222
Replacing a PTX5000 PIC SFP+ Transceiver
1.
Removing a PTX5000 PIC SFP+ Transceiver on page 185
2.
Installing a PTX5000 PIC SFP+ Transceiver on page 186
Copyright © 2012, Juniper Networks, Inc.184
PTX5000 Packet Transport Switch Hardware Guide
