Table 25: Accessory Box Parts List (continued)
QuantityPart
3Screws to fasten grounding cable to chassis,
Phillips, 1/4-20 x 3/8
20
NOTE: One cable lug is for the grounding cable.
NOTE: 16 cable lugs are for the DC power
cables.
0-AWG DC power and grounding cable lugs
3Connectors for alarm relay cables, Terminal
Block Plug, 3 Pole, 5.08 mm spacing, 12 A
1End User License Agreement (EULA)
1ROHS and warranty card
115-ft Ethernet cable to connect the Routing
Engine to a management device (RJ-45
connectors, 4-pair stranded UTP, Category 5E)
17-ft serial cable to connect the Routing Engine
to a management console (DB9 to RJ-45
adapter, straight through)
1ESD wrist strap with cable
Related
Documentation
• Overview of Unpacking the PTX5000 Packet Transport Switch on page 61
• Unpacking the PTX5000 Packet Transport Switch on page 62
65Copyright © 2012, Juniper Networks, Inc.
Chapter 6: Unpacking the PTX5000 Packet Transport Switch
