Keysight B2961A/B2962A SCPI Command Reference, Edition 6 4- 153
Subsystem Commands
STATus Subsystem
Table 4-5 Measurement Status Condition Register Bit Definitions
8 256 Calibration Channel 1 and/or 2 failed calibration.
9 512 Self-test Channel 1 and/or 2 failed self-test.
10 1024 Interlock Interlock circuit is open.
11 2048 Ch1 Transition Event Lost Lost arm or trigger transition event on channel 1
12 4096 Ch1 Acquire Event Lost Lost arm or trigger acquire event on channel 1
13 8192 Ch2 Transition Event Lost Lost arm or trigger transition event on channel 2
14 16384 Ch2 Acquire Event Lost Lost arm or trigger acquire event on channel 2
15 Not used 0 is returned.
bit
decimal
value
description definition
0 1 Not used 0 is returned.
1 2 Ch1 Reading Available Reading of channel 1 was taken normally.
2 4 Ch1 Reading Overflow Reading of channel 1 exceeds the selected
measurement range.
3 8 Ch1 Buffer Available Trace buffer for channel 1 has data.
4 16 Ch1 Buffer Full Trace buffer for channel 1 is full.
5 32 Not used 0 is returned.
6 64 Not used 0 is returned.
7 128 Ch2 Reading Available Reading of channel 2 was taken normally.
8 256 Ch2 Reading Overflow Reading of channel 2 exceeds the selected
measurement range.
9 512 Ch2 Buffer Available Trace buffer for channel 2 has data.
10 1024 Ch2 Buffer Full Trace buffer for channel 2 is full.
11 to 15 Not used 0 is returned.
bit
decimal
value
description definition
