4- 154 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Commands
STATus Subsystem
Table 4-6 Operation Status Condition Register Bit Definitions
bit
decimal
value
description definition
0 1 Calibration/Self-test Running Self-calibration or Self-test is in progress.
1 2 Ch1 Transition Idle Channel 1 is in the transition idle state.
2 4 Ch1 Waiting for Transition Trigger Channel 1 is waiting for the transition trigger.
3 8 Ch1 Waiting for Transition Arm Channel 1 is waiting for the transition arm.
4 16 Ch1 Acquire Idle Channel 1 is in the acquire idle state.
5 32 Ch1 Waiting for Acquire Trigger Channel 1 is waiting for the acquire trigger.
6 64 Ch1 Waiting for Acquire Arm Channel 1 is waiting for the acquire arm.
7 128 Ch2 Transition Idle Channel 2 is in the transition idle state.
8 256 Ch2 Waiting for Transition Trigger Channel 2 is waiting for the transition trigger.
9 512 Ch2 Waiting for Transition Arm Channel 2 is waiting for the transition arm.
10 1024 Ch2 Acquire Idle Channel 2 is in the acquire idle state.
11 2048 Ch2 Waiting for Acquire Trigger Channel 2 is waiting for the acquire trigger.
12 4056 Ch2 Waiting for Acquire Arm Channel 2 is waiting for the acquire arm.
13 8192 Instrument Locked If a remote interface (GPIB, USB, or LAN)
has a lock (see
:SYSTem:LOCK:OWNer?
command), this bit will be set. When a
remote interface releases the lock (see
:SYSTem:LOCK:NAME? command), this
bit will be cleared.
14 16384 Program Running Program is running. 0 is set during the
program memory execution is stopped.
15 32768 Not used 0 is returned.
