Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 21
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR]:DIG:EXT[n]:TOUT[:EDGE]:P
OS position
[:SOUR]:DIG:EXT[n]:TOUT[:EDGE]:P
OS?
Selects the trigger output timing for the
specified GPIO pin.
position=BEFore|AFTer|BOTH
BOTH
[:SOUR]:DIG:EXT[n]:TOUT[:EDGE]:W
IDT width
[:SOUR]:DIG:EXT[n]:TOUT[:EDGE]:W
IDT? [DEFault|MINimum|MAXimum]
Sets the pulse width of the output trigger
for the specified GPIO pin.
width=MINimum|MAXimum|DEFault|
1E-5 to 1E-2 seconds
1.00E-04
seconds
[:SOUR]:DIG:EXT[n]:TOUT:TYPE typ
e
[:SOUR]:DIG:EXT[n]:TOUT:TYPE?
Selects the output trigger type for the
specified GPIO pin.
type=EDGE|LEVel
EDGE
[:SOUR]:DIG:INT[i]:TOUT[:EDGE]:P
OS position
[:SOUR]:DIG:INT[i]:TOUT[:EDGE]:P
OS?
Selects the trigger output timing for the
internal trigger line 1 or 2.
position=BEFore|AFTer|BOTH
BOTH
[:SOUR[c]]:FUNC:MODE mode
[:SOUR[c]]:FUNC:MODE?
Selects the source output mode of the
specified channel.
mode=CURRent|VOLTage
VOLT
[:SOUR[c]]:FUNC[:SHAP] type
[:SOUR[c]]:FUNC[:SHAP]?
Selects the source output type of the
specified channel.
type=PULSe|DC
DC
[:SOUR[c]]:FUNC:TRIG:CONT mode
[:SOUR[c]]:FUNC:TRIG:CONT?
Enables or disables continuous trigger
output for the specified channel.
mode=0|OFF|1|ON
OFF
[:SOUR[c]]:LIST:CURR list
[:SOUR[c]]:LIST:VOLT list
[:SOUR[c]]:LIST:CURR?
[:SOUR[c]]:LIST:VOLT?
Sets the source output current or voltage
data for the specified channel.
list: List of the output current or voltage
data. Maximum of 100000 data can be set
to list. Each data must be separated by a
comma.
0
Command Summary Reset setting
