2- 20 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:CURR:STEP step
[:SOUR[c]]:VOLT:STEP step
[:SOUR[c]]:CURR:STEP? [DEFault|
MINimum|MAXimum]
[:SOUR[c]]:VOLT:STEP? [DEFault|
MINimum|MAXimum]
Sets the sweep step value of the current or
voltage sweep output.
step=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
The step value can be expressed by the
following formula, using the points value
set by the
[:SOUR[c]]:<CURR|VOLT>:POIN
command and the span value set by the
[:SOUR[c]]:<CURR|VOLT>:SPAN
command.
step = span/(points - 1) (where points is
not 1)
points=1 sets step=0.
0
[:SOUR[c]]:CURR:TRAN:SPE mode
[:SOUR[c]]:VOLT:TRAN:SPE mode
[:SOUR[c]]:CURR:TRAN:SPE?
[:SOUR[c]]:VOLT:TRAN:SPE?
Selects the transient speed mode, normal
or fast, of the specified source channel.
mode=NORMal|FAST
NORM
[:SOUR]:DIG:DATA data
[:SOUR]:DIG:DATA?
Sets the output data to the GPIO pins
(digital control port) and read data from
the GPIO pins.
data=0 to 16383
[:SOUR]:DIG:EXT[n][:FUNC] functi
on
[:SOUR]:DIG:EXT[n][:FUNC]?
Assigns the input/output function to the
specified GPIO pin.
function=DIO|DINPut|HVOL|TINPut|
TOUT
DINP for
EXT1 to 13,
HVOL for
EXT14
[:SOUR]:DIG:EXT[n]:POL polarity
[:SOUR]:DIG:EXT[n]:POL?
Sets the polarity of the input/output
function for the specified GPIO pin.
polarity=NEG|POS
NEG for
EXT1 to 13,
POS for
EXT14
Command Summary Reset setting
