Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 19
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:CURR:RANG:AUTO:LLIM r
ange
[:SOUR[c]]:VOLT:RANG:AUTO:LLIM r
ange
[:SOUR[c]]:CURR:RANG:AUTO:LLIM?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:VOLT:RANG:AUTO:LLIM?
[DEFault|MINimum|MAXimum]
Specifies the lower limit for the automatic
output ranging operation, and sets the
minimum range which provides the best
resolution to apply the specified value.
range=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
1.00E-06 A
for current
range, or 0.2
V for voltage
range
[:SOUR[c]]:CURR:RANG:RPR mode
[:SOUR[c]]:VOLT:RANG:RPR mode
[:SOUR[c]]:CURR:RANG:RPR?
[:SOUR[c]]:VOLT:RANG:RPR?
Selects the output pulse priority mode,
low noise priority or transient speed
priority, of the specified source channel.
mode=NOISe|TRANsient
NOIS
[:SOUR[c]]:CURR:STAR data
[:SOUR[c]]:VOLT:STAR data
[:SOUR[c]]:CURR:STAR? [DEFault|
MINimum|MAXimum]
[:SOUR[c]]:VOLT:STAR? [DEFault|
MINimum|MAXimum]
Sets the start or stop value for the current
or voltage sweep output.
data=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
The start and stop values can be
expressed by the following formula,
using the center and span values set by
the
[:SOUR[c]]:<CURR|VOLT>:<CENT|
SPAN> command. So the last command
setting is effective for these sweep
parameters.
start = center - span/2
stop = center + span/2
0
[:SOUR[c]]:CURR:STOP data
[:SOUR[c]]:VOLT:STOP data
[:SOUR[c]]:CURR:STOP? [DEFault|
MINimum|MAXimum]
[:SOUR[c]]:VOLT:STOP? [DEFault|
MINimum|MAXimum]
0
Command Summary Reset setting
