Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 35
Subsystem Command Summary
Setting Source Output and Measurement
:OUTP[c]:RES:EMUL:CURR:POIN?
:OUTP[c]:RES:EMUL:VOLT:POIN?
:OUTP[c]:RES:EMUL:MODE:POIN?
Returns the number of data in the list set
by the :OUTP:RES:EMUL:<CURR|
VOLT|MODE> command.
2 for CURR
and VOLT
1 for MODE
:OUTP[c]:RES:MODE mode
:OUTP[c]:RES:MODE?
Selects the operation mode of the
programmable output resistance function.
mode=FIXed|EMULate
FIX
:OUTP[c]:RES:SER[:LEV] level
:OUTP[c]:RES:SER[:LEV]? [DEFault
|MINimum|MAXimum]
Sets the series resistance used for the
fixed mode operation of the
programmable output resistance function.
level=MINimum|MAXimum|DEFault|
-20 MΩ to +20 MΩ
0
:OUTP[c]:RES:SHUN[:LEV] level
:OUTP[c]:RES:SHUN[:LEV]? [DEFaul
t|MINimum|MAXimum]
Sets the shunt resistance used for the
fixed mode operation of the
programmable output resistance function.
level=MINimum|MAXimum|DEFault|
0.2
Ω to 2 GΩ
2 GΩ
:OUTP[c]:RES:STAT mode
:OUTP[c]:RES:STAT?
Enables or disables the programmable
output resistance function.
mode=1|ON|0|OFF
OFF
:OUTP[c]:SAVE index
Saves the channel setup. The setup can be
recalled by the :OUTP:REC command.
index=0 or 1 to memorize the present
channel setup as the channel setup 0 or 1.
:OUTP[c][:STAT] mode
:OUTP[c][:STAT]?
Enables or disables the source output.
mode=1|ON|0|OFF
OFF
Command Summary Reset setting
