Keysight Technologies B2961A Command Reference

Keysight B2961A/B2962A SCPI Command Reference, Edition 6 2- 37
Subsystem Command Summary
Setting Source Output and Measurement
Table 2-6 Current Output Range
Range
value
Setting resolution
DC output current or
pulse peak/base
current
a b
Maximum voltage
Pulse width t
c
DC
output
Pulsed
output
10 nA 10 fA 0 ≤ |I| ≤ 10.5 nA ±210 V ±210 V 50 μs ≤ t ≤ t
max
100 nA 100 fA 0 ≤ |I| ≤ 105 nA
1 μA 1 pA 0 ≤ |I| ≤ 1.05 μA
10 μA 10 pA 0 ≤ |I| ≤ 10.5 μA
100 μA 100 pA 0 ≤ |I| ≤ 105 μA
1 mA 1 nA 0 ≤ |I| ≤ 1.05 mA
10 mA 10 nA 0 ≤ |I| ≤ 10.5 mA
100 mA 100 nA 0 ≤ |I| ≤ 105 mA
1 A 1 μA 0 ≤ |I| ≤ 105 mA
105 mA < |I| ≤ 1.05 A ±21 V ±21 V
0 ≤ |I| ≤ 1.05 A ⎯ ±200 V 50 μs ≤ t ≤ 2.5 ms
⎯ ±180 V 50 μs ≤ t ≤ 10 ms
1.5 A 0 ≤ |I| ≤ 105 mA ±210 V ±210 V 50 μs ≤ t ≤ t
max
105 mA < |I| ≤ 1.515 A ±21 V ±21 V
0 ≤ |I| ≤ 1.515 A ⎯ ±200 V 50 μs ≤ t ≤ 2.5 ms
0 ≤ |I| ≤ 1.05 A ⎯ ±180 V 50 μs ≤ t ≤ 10 ms
3 A 10 μA 0 ≤ |I| ≤ 105 mA ±210 V ±210 V 50 μs ≤ t ≤ t
max
105 mA < |I| ≤ 1.515 A ±21 V ±21 V
1.515 A < |I| ≤ 3.03 A ±6 V ±6 V
10 A 0 ≤ |I| ≤ 10.5 A ⎯ ±6 V 50 μs ≤ t ≤ 1 ms
0 ≤ |I| ≤ 1.515 A ⎯ ±200 V 50 μs ≤ t ≤ 2.5 ms
0 ≤ |I| ≤ 1.05 A ⎯ ±180 V 50 μs ≤ t ≤ 10 ms
