Keysight N1911A

2 General Power Meter Functions
102 Keysight N1911A/1912A User’s Guide
Figure 2-42 Trigger Hysteresis pop-up
Complete the entry by pressing .
Output
The current setting is displayed below the label. A TTL level high is
produced at the rear panel TRIG OUT BNC connector when the power meter is
triggered when is configured.
To change the setting, press to highlight or as required.
dB
Output
On
Output
On
Off
