Figure 1-4 Trace display in both windows
22 Figure 1-4 shows both windows configured to trace display mode. This is only
available with an P-Series or an E-Series E9320 power sensor is connected.
The captured trace, channel, and scaling are displayed. The lower window is
the selected window.
23 The indicates the point on the trace where trigger event occurs.
Single or continuous triggering ( or ) must be selected from
the Acqn menu to view a trace window. The Acqn menu is accessed by pressing
, . is disabled when is selected.
