Using E9320 E-Series Power Sensors 4
Keysight N1911A/1912A User’s Guide 181
Improving the accuracy with additional settings
You can now return to the setup menus and adjust the default setting to obtain
greater measurement accuracy.
Channel Setup
Press . The Channel Setup screen is displayed. If using an N1912A, select
the channel you want to configure.
Figure 4-11 E-Series E9320 power sensor default channel setup
Use the , , , and keys to highlight the setting field and press
to configure the setting. For further detail on these settings, refer to the
appropriate sections.
Meas Avg
: “Setting Measurement Averaging” on page 78
Video Avg
: “Setting the Video Averaging” on page 82
Step Detec
t: “Step Detection” on page 81
Video B/W
: “Setting the Video Bandwidth” on page 84
For range settings, only UPPER and LOWER ranges are available in Normal and
Triggered mode.
