2 General Power Meter Functions
112 Keysight N1911A/1912A User’s Guide
Frequency sweep mode
Frequency sweep is generally used in a frequency response calibration system
where the amplitude is fixed, and the frequency of the power source signal is
swept. This mode can be used to determine the frequency response of a device
under test.
Procedures
1 Connect sensor to a power source.
2 Connect power meter TRIG OUT to power source TRIG IN using a BNC cable.
The same connection is applied for power source TRIG OUT to power meter
TRIG IN. See Figure 2-43.
3 Press . The Channel Setup displays as shown in Figure 2-44.
This feature is only available when N8480 Series, E-Series E4410, E-Series
E9300, E-Series E9320 or P-Series N1920 sensor is connected.
When N8480 Series, E-Series E4410 or E-Series E9300 sensor is connected,
Sensor Mode is set to AVG only by default.
