General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 89
2 Press and use the numeric keypad to enter the required value in the
Time Gating Start pop-up window.
Figure 2-24 Time Gating Start pop-up
3 Complete the entry by pressing the required second, millisecond, microsecond
or nanosecond ( , , or ) softkey.
4 Highlight the Gate Length you want to configure using the , , , and
keys.
Figure 2-25 Time Gating Length pop-up
5 Complete the entry by pressing the required second, millisecond, or
microsecond or nanosecond ( , , or ) softkey.
6 Repeat this process until you have setup all the required gates.
