General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 107
4 Press . The Trigger menu is displayed.
5 Press softkey to configure the trigger.
6 Select either or .
– is a single shot mode. After triggering, the measurement is
halted, and the symbol is displayed. You can start another measurement
by pressing the key.
– is a continuos trigger mode. The symbol or is displayed.
When E-Series E9320 or P-Series N1920 sensor is connected, the default sensor
mode is Normal. User can use this Normal mode to perform power or frequency
sweep, or change the mode to AVG only to perform power or frequency sweep.
Refer Table 2-5 on the differences in measurement functions supported under
these two modes.
To change the sensor mode from the default Normal mode to AVG only mode,
follow the instructions below:
– Press . Use the and keys to highlight the Sensor Mode field.
– Press to display the Sensor Mode pop-up.
Figure 2-45 Sensor Mode pop-up.
– Use the and keys to highlight the AVG and press .
