3 Use the numeric keys to complete the entry and press softkey.
4 Press softkey. The Marker 2 Ref Percentage pop-up is
displayed.
Figure 2-28 Marker 2 Ref Percentage pop-up
5 Use the numeric keys to complete the entry and press softkey.
Figure 2-29 The placement of gates (markers) in Auto Gating mode
Ref 1 x PD
Ref 2 x PD
Pulse Duration (PD)
Enabling the softkey allows the gates to be repositioned
automatically according to the changes of pulse duration.
