Keysight N1911A

General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 123
Figure 2-53 Measurement feed example
Each displayed line has a measurement feed. Each measurement feed has two
independent inputs, Feed 1 and Feed 2. The two Feeds, 1 and 2, can carry any of
the 16 measurement results from the 4 gates. (32 measurements from 8 gates in
the dual channel N1912A). Only Feed 1 can be displayed in Single Mode. In
Combined Mode, Feed 1 - Feed 2 or Feed 1 / Feed 2 can be displayed.
Peak
Average
Pk-to-Avg
Gate 1
Peak
Average
Pk-to-Avg
Feed 1
Feed 2
Feed 1
Feed 2
Feed 1
Feed 2
Feed 1
Feed 2
Single
Combined
Gate 2
Gate 3
Gate 4
Measurement Feeds
(single or combined)
16/32 Measurement Highway
Feed 1-Feed 2
Feed 1/Feed 2
Single
Combined
Feed 1-Feed 2
Feed 1/Feed 2
Single
Combined
Feed 1-Feed 2
Feed 1/Feed 2
Single
Combined
Feed 1-Feed 2
Feed 1/Feed 2
Min
Min
Min
Min
Peak
Average
Pk-to-Avg
Peak
Average
Pk-to-Avg
