Keysight N1911A

Using E4410 E-Series Power Sensors 6
Keysight N1911A/1912A User’s Guide 203
Power Meter Configuration
The P-Series power meters automatically recognize an E-Series E4410 power
sensor when it is connected. The sensor calibration data is automatically read by
the power meter. Also, the power meter automatically configures the averaging as
shown in Figure 6-1.
Figure 6-1 E-Series CW sensor auto-averaging settings
10 dB
10 dB
Maximum Sensor Power
Minimum Sensor Power
10 dB
10 dB
1234
1118
Resolution Setting
Number of Averages
11116
11232
1 1 16 256
1 8 128 128
Power Sensor Dynamic Range
NOTE
These values are valid only for the power meter channel connected with E-Series
E4410 power sensor. Averaging settings can also be manually configured.
