Using 8480 Series Power Sensors 7
Keysight N1911A/1912A User’s Guide 215
Does this setting match the value for the sensor? (The power sensor reference
calibration factor can normally be found above the calibration factors table on the
power sensor body.)
10 To change the settings, use the and keys to highlight the Cal Fac value
field and press to display the Cal Factor pop-up. Use the numeric
keypad to enter the required value in the Cal Factor pop-up window.
Figure 7-4 Calibration factor pop-up window
11 Press
to complete the entry.
12 Connect the power sensor to the signal to be measured.
13 The corrected measurement result is displayed.
Figure 7-5 Calibration factor display
Example
