General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 125
Single function measurement
Figure 2-54 shows Gate 1 with an average measurement assigned in the upper
measurement line of the lower window. (For single channel power meter
(N1911A), the Channel field will be disabled, as shown in Figure 2-54).
1 Use the , , , , to highlight the Combination function field.
2 Press to display the Function pop-up, and use the and to
highlight Single.
Figure 2-55 Function pop-up
3 Press to complete the entry.
4 Use the , , , , to highlight the measurement type field.
The gate field is disabled if trigger acquisition is Free Run.
