2 General Power Meter Functions
70 Keysight N1911A/1912A User’s Guide
Setting display offsets
This gain or loss is applied to the measured power after any channel offsets or
mathematical functions have been included.
Offsets are entered in dB and the range of values is –100 dB to +100 dB. A
positive value compensates for a loss, and a negative value compensates for a
gain.
Procedure
Enter a display offset on the currently selected window:
1 Press to display the Measurement Setup screen.
2 Select the window you wish to set the offset value on by pressing the
key. The currently selected window/measurement is displayed.
3 Use the and keys to highlight the Offset setting field.
4 Press to check the Offset setting field.
Figure 2-12 Typical display offset display
Offset setting field
Offset value field
Selected
Window/
Measurement
