9 Complementary Cumulative Distribution Function (CCDF)
254 Keysight N1911A/1912A User’s Guide
Expanded CCDF table
Press once for an expanded view of the CCDF table.
Figure 9-2 CCDF table in expanded display
In expanded format, you are allowed to query the power (dB) and the probability
(%) based on your input. You can also vary the sample count of the CCDF table.
To set the sample count, press then . You can
also set the mode to single or continuous. In single mode, the graph and table
readings will stop refreshing after the desired elapsed count is acquired. In
continuous mode, the graph and table readings will reset after each cycle of
elapsed count.
The mode can be set by pressing .
The minimum elapsed count is 100 M, while the maximum is 10 G.
Statistical Settings can also be accessed in Marker Ctrl menu.
