Step 1. Connecting the power sensor
When you initially connect an E-Series E9320 power sensor to the power meter,
the sensor’s calibration data is automatically read by the power meter. After every
power cycle, the E9320 must perform zero and calibration as the P-Series power
meters do not retain the states and settings upon power cycle (warm start
feature).
Connect the sensor to the power source.
Step 2. Setting the channel frequency
– Press . The Channel Setup screen is displayed. If using an N1912A,
select the channel you want to configure.
– Use the , , , and keys to highlight the frequency field. Press
to configure the setting. See “Setting the Measurement Frequency” on
page 60 for further information.
When you have completed the procedure you can return to this menu later to add
more accuracy to the measurement.
Step 3. Setting the trigger
To use the measurement gates the power meter must be triggered.
A trigger can be taken from a rising or falling measured power level or controlled
externally using the Ext Trig input.
Press . The Trigger menu is displayed.
The trigger status is displayed below the label in the Trigger menu. Press
the softkey and select to configure continuous triggering.
When you have completed the procedure you may return to the Trigger menu
later to add more accuracy to the remaining trigger parameters, to help you
achieve a stable and reliable trigger.
