Using P-Series Power Sensor 3
Keysight N1911A/1912A User’s Guide 153
Step 1. Connecting the power sensor
When you initially connect a P-Series wideband power sensor to the power meter,
the sensor’s calibration data is automatically read by the power meter. After the
sensor’s data is read, the power meter automatically performs a zero and
calibration, see “Zeroing and Calibrating the P-Series Sensor” on page 140 for
further information.
Connect the sensor to the power source.
Step 2. Setting the channel frequency
Press . The Channel Setup screen is displayed. If using an N1912A, select
the channel you want to configure.
Use the , , , and keys to highlight the frequency field. Press to
configure the setting. See “Setting the Measurement Frequency” on page 60 for
further information.
Figure 3-1 P-Series sensor default channel setup
By default the sensor mode is set to Normal, users are allowed to change to AVG
only mode whereby all the peak power measurement functions will be disabled.
