2 General Power Meter Functions
92 Keysight N1911A/1912A User’s Guide
Setting up the Channel Trace
Procedure
1 Press , to display the Trace Setup menu.
Figure 2-30 Trace setup display
This feature is only available when a P-Series or an E-Series E9320 power sensor
is connected.
The Trace Setup is the only location where you can change the Y-axis units from
dBm to Watts.
This procedure uses the Trace Setup under the Channel Setup menu.
Alternatively, you can use a more visual method, when in the Graphical Trace
Mode (Trace Control Menu), to set the channel’s Trace Control. (See “Setting the
Trace Display” on page 152).
