Keysight N1911A

General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 93
2 Use the and keys to highlight the X Start field.
3 Press to display the Trace Start Time pop-up and use the numeric
keypad to enter the required value in the Trace Start Time pop-up window.
Figure 2-31 Trace Start Time pop-up
4 Complete the entry by pressing the required second, millisecond, microsecond
or nanosecond ( , , or ) softkey.
5 Use the and keys to highlight the X Scale field.
6 Press to display the X Scale/Division pop-up.
a Use the numeric keypad to enter the required value in the X Scale/Division
pop-up window.
b Use the and keys to increase or decrease the value.
Figure 2-32 X Scale/Division pop-up
7 Complete the entry by pressing:
a The required second, millisecond, microsecond or nanosecond ( , ,
or ) softkey.
s
ms
μs
ns
s
ms
μs
ns
