8 Using N8480 Series Power Sensors
236 Keysight N1911A/1912A User’s Guide
Now set the frequency of the signal you want to measure. The power meter
automatically selects the appropriate calibration factor.
6 Press . On dual channel meters select the required channel.
7 Use the and keys to highlight the Frequency value field and press
to display the Frequency pop-up. Use the numeric keypad to enter the
required value in the Frequency pop-up window.
Figure 8-4 Frequency pop-up
8 Confirm your choice by pressing or .
9 Press key to close the Channel Setup screen.
Now make the measurement.
10 Connect the power sensor to the signal to be measured.
The corrected measurement result is displayed.
You can reduce the steps required to carry out the zero and calibration
procedure as follows:
1 Connect the power sensor to the POWER REF output.
2 Press and . (For dual channel meters, press
,, or as required).
