General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 129
Scaling the Analog Display
Configure a measurement displayed in format as follows:
1 Press , to display the Analog Scaling softkeys.
The and scale values are shown on the analog display and adjacent
to the softkey labels.
2 Press to display the Meter Maximum pop-up.
Figure 2-60 Maximum limit pop-up
3 Use the numeric keys to enter the required value and press .
Ensure you have highlighted an Analog window.
Use the , , or keys to select the analog measurement window.
Press , , , or , to complete the entry.
