General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 137
Saving and Recalling Power Meter States
To reduce repeated setup sequences, you can save a maximum of ten power
meter states in the non-volatile memory.
The save/recall functions are part of the Sys/Inputs menu, accessed by pressing
the key.
To save a measurement setup:
1 Press , to display the Save/Recall screen as shown in
Figure 2-68.
Figure 2-68 Save/Recall screen
2 Using the and keys, select an available name from the displayed list. To
change the name of a register -See Chapter 2, “Editing a register’s name,”
starting on page 138, otherwise press .
Your power meter has measurement configurations suitable for common
wireless communication and radar (pulse) formats already saved as Instrument
Presets. These require P-Series or E-Series E9320 power sensors.
