General Power Meter Functions 2
Keysight N1911A/1912A User’s Guide 75
Editing frequency dependent offset tables requires the following steps:
1 Identify and select the table you want to edit
2 Rename the table
3 Enter the frequency and offset pairs
4 Save the table
Procedure
First select the table you want to edit as follows:
1 Press , , to display the Offset Tbls screen.
2 Choose the table you want to edit using the and keys. Press
to display the Edit Offset screen as shown in Figure 2-15.
Figure 2-15 “Edit Offset” display with data added
A frequency in the range of 0.001 MHz to 1000.0 GHz can be entered. A
calibration factor in the range of 1% to 150% can be entered.
