Using 8480 Series Power Sensors 7
Keysight N1911A/1912A User’s Guide 209
Power Meter Configuration
The P-Series power meters automatically recognize an 8480 Series power sensor
when it is connected. The averaging settings shown in Figure 7-1 are
automatically configured.
Figure 7-1 8480 Series auto-averaging settings
10 dB
10 dB
Maximum Sensor Power
Minimum Sensor Power
Power Sensor
Dynamic Range
10 dB
10 dB
1234
1118
Resolution Setting
Number of Averages
11116
11232
1 1 16 256
1 8 128 128
These values are valid only for the power meter channel connected with
Keysight 8480 Series power sensors. Averaging settings can also be manually
configured.
