Keysight N1911A

Introduction 1
Keysight N1911A/1912A User’s Guide 53
Table 1-1 Type of Lan Status message
Figure 1-12 Example of Lan Status message
Type of message Description
Lan: No Fault
Status: Initialized
– A valid IP address is successfully obtained using selected LAN
configuration and the network state is initialized.
Lan: No Fault
Status: Running
– A valid IP address is successfully obtained using selected LAN
configuration, while network is running.
Lan: Fault
Status: Initialization failed
– IP conflict occurs, or
– IP address failed to be obtained using selected LAN
configuration, or
– No LAN configuration is selected.
Lan: Fault
Status: Disconnected
– LAN cable is unplugged.
Lan: –
Status: Restarting
– Restart the network and try to obtain an IP address using
selected LAN configuration.
Lan: DHCP Not Available
Status: Running
– Unable to obtain IP address from DHCP server (if user select
DHCP configuration)
– IP address obtained from Auto-IP or manual configuration.
