Complementary Cumulative Distribution Function (CCDF) 9
Keysight N1911A/1912A User’s Guide 257
Step 2: Setting the Marker
By using the marker, you can retrieve the data in between the limits of the X-axis
that have been set.
– Return to Marker Ctrl menu.
– Press .
– Press and to select Marker 1 or Marker 2.
– Press , , , or to select the trace that you
wish the marker to be placed on.
Figure 9-5 CCDF trace display with Marker Trace menu
– Press to return to the Marker Ctrl menu.
– Press to select the marker.
– Press and to move the marker to get to the required location.
Selected marker will have a green line outlining either Row 1 or Row 2.
