5 Using E9300 E-Series Power Sensors
190 Keysight N1911A/1912A User’s Guide
Procedure
First zero and calibrate the power meter/sensor combination.
1 Ensure the power sensor is disconnected from any signal source.
2 Press and the channel softkey. The Zeroing pop-up is
displayed.
3 Connect the power sensor to the POWER REF output.
4 Press and the channel softkey to start the calibration routine.
The Calibrating pop-up is then displayed.
Now set the frequency of the signal you want to measure. The power meter
automatically selects the appropriate calibration factor.
5 Press . On dual channel meters select the required channel.
6 Use the and keys to highlight the Frequency value field and press
to display the Frequency pop-up. Use the numeric keypad to enter the
required value in the Frequency pop-up window.
You can reduce the steps required to carry out the zero and calibration
procedure as follows:
1 Connect the power sensor to the POWER REF output.
2 Press and . (For dual channel meters, press
, or as required).
