Keysight N1911A

3 Using P-Series Power Sensor
164 Keysight N1911A/1912A User’s Guide
Measurement Setup
Press . The Measurement Setup menu is displayed.
Use the , , , and keys to highlight the setting field and press
to configure the setting.
When you have configured the measurements gates, you can assign the
measurement feed and display the results in numeric formats. For example, dual
numeric display with Gate 1 peak measurement minus Gate 3 peak measurement.
Also, from this menu you can add offsets and measurement limits. For further
detail on these settings, refer the appropriate section.
Feed1/2 “Setting the Measurement Display” on page 122
Offset
“Setting display offsets” on page 70
Limits
“Setting Measurement Limits” on page 118
Display
Press . The Display Form menu is displayed.
Choose the display format to present the measurements results. The options,
other than trace, are as follows:
Single Numeric If you need to configure the numeric format when using a
P-Series sensor, refer to “Numeric format” on page 124 for more details.
Dual Numeric If you need to configure the numeric format when using a
P-Series sensor, refer to “Numeric format” on page 124 for more details.
Analog If you need to configure the analog format when using a P-Series
sensor refer to “Scaling the Analog Display” on page 129 for more details.
