4 Using E9320 E-Series Power Sensors
178 Keysight N1911A/1912A User’s Guide
TgDel
When is selected you can adjust the trigger delay. The display changes to
remove the gate markers and displays the trigger marker(s). The indicates
when the trigger event occurs, whilst shows the delayed trigger point. When
the two points coincide, only the trigger is shown.
The configured value is displayed below the softkey. This value is
shown in Figure 4-8.
To indicate an off-screen trigger event, is displayed. To indicate an off-screen
trigger point, is displayed.
Trig Delay
The trigger delay value is shown below the softkey. You configure the
trigger delay by pressing and entering a numeric value in the pop-up
window.
Pressing highlights to display the trace markers again.
Trace Control
Press to display the Trace Control menu. Setting the trace features
are described in greater details in “Setting up the Channel Trace” on page 92.
Your chosen trigger point is used as the reference point for the timing of all the
measurement gates.
You can also setup the trigger delay in the Trigger menu, by pressing ,
and entering a value in the pop-up window.
