Keysight N9038A MXE Service Guide 21
Overview
Instrument Option Descriptions
Instrument Option Descriptions
The MXE EMI Receiver has a variety of hardware and measurement application
options. Several of these options are “standard” so they are automatically
installed on all MXE instruments. All options require license files to be present
in instrument memory before the option can be used, or viewed on the System
configuration screen.
From the front panel, press System, Show, System to view a list of all installed
options.
A current list of all instrument options and retrofit requirements is available on
the Keysight web site at:
www.keysight.com/find/mxe
Option Description Notes
503 20 Hz to 3.6 GHz Frequency Range
508 20 Hz to 8.4 GHz Frequency Range
526 20 Hz to 26.5 GHz Frequency Range
544 20 Hz to 44 GHz Frequency Range
B25 25 MHz Analysis Bandwidth
B85 85 MHz Analysis Bandwidth
C35 3.5 mm RF Input
CNF
a
Type-N Female RF input Not Licensed
CR3 Wideband IF Output
Included on all units
b
DP2 High Performance Digital Signal Processing
Included on all units
b
EDP Enhanced Display Package Included on all units
EMC Software only. Provides EMI detectors and BWs. Included on all units
EXM External Mixing
FSA
a
Fine Step Attenuator Included on all units
LSN External LISN Control
Included on all units
b
NFE Noise Floor Extension Included on all units
PFR Precision Frequency Reference Included on all units
P03 Preamp, 100 kHz to 3.6 GHz Included with Option 503
P08 Preamp, 100 kHz to 8.4 GHz Included with Option 508
