750 Keysight N9038A MXE Service Guide
Tests
RMS Average Detector Accuracy
21.Calculate the Error with the following formula and enter the value in Table
22-63.
Error = Measured – 40 dBµV + 4.55 dB - Error (Table 22-62)
22.Put the marker in Delta mode by pressing Marker, Delta.
23.Turn on the continuous peak function by pressing Peak Search, More,
Continuous Peak Search On.
24.Change the Pulse Frequency on the IGUU 2916 EMI pulse generator to
100 Hz.
25.Take a single sweep on the EMI receiver by pressing Restart.
26.Once the sweep on the EMI receiver has completed and the auto peak
value is found record the marker delta amplitude value for the pulse
frequency being measured in Table 22-64.
27.Without changing any other setting on the EMI receiver or the IGUU 2916
EMI pulse generator change the Pulse Frequency on the pulse generator
to the other values in the Table 22-64 and repeat steps 25 and 26 for each.
Band C Testing
1. Set the IGUU 2916 EMI pulse generator to output a 100 MHz Sine Wave
signal.
Table 22-63 RMS Average Amplitude Relationship Band B – CISPR 16-1-1 :2010 Section 7.5.2
Pulse Frequency
(Hz)
Band B
Measured
(dBµV)
Lower Limit
(dB)
Error
(dB)
Upper Limit
(dB)
1000 -2.0 +2.0
Table 22-64 RMS Average Variation with Repetition Frequency
Band B – CISPR 16-1-1 :2010 Section 7.5.3
Pulse Frequency
(Hz)
Band B
Lower Limit
(dB)
Measured
(dB)
Upper Limit
(dB)
1000 0 Reference 0
100 -11.5 -8.5
25 -18.1 -13.9
10 -22.5 -17.5
5 -27.8 -22.2
